SFF150

FIREFIGHTER SAFETY SWITCH 1 STRING

Firefighter Switch SFF150 for 1 String, is a safety solution designed to protect firefighters and emergency teams operating in fires or critical situations in photovoltaic installations. This device enables a fast and secure disconnection of solar systems, minimizing the risk of electrocution during rescue operations. Dimensions: 204x194x105 mm in a compact PC+ABS enclosure.

Print to PDF

Code 029SFF150
EAN 8430892354486
Dimensions
Product height 194 mm
Product width 204 mm
Product length 105 mm
Product weight (kg) 1.2
SFF Technical Data
Number of Strings 1
String voltage (Ue) 300...1500 VDC
AC disconnection circuit 230 V - 30 mA
String current 600 V 55 A
String current 1000 V 50 A
String current 1500 V 30 A
Temperature automatic shutdown 70ºC / 158ºF
Safe quick connection MC4
Protection degree IP66
Enclosure material PC-ABS
Base colour RAL 9006
Cover colour RAL 7038
Weathrproof ventilation valv 1
Standards IEC 60947-3 - DC-PV1
