SFC06C

FIREFIGHTER CONTROL BOX FOR 6 SFF

The Control Box for 6 Firefighter Switches (SFF) is an essential component in installations where emergency fire disconnect devices are implemented. Designed to centralize and manage up to eight SFF units, this box enables monitoring, signaling, and remote control of the connected safety systems.

  • Equipped with green LEDs to indicate the operational status of each SFF and quickly detect any faults visually.

  • When connected to the fire alarm panel, it allows automatic opening of all SFFs in the event of an alarm, while also activating a red optical indicator to signal the emergency state.

  • Allows simultaneous opening of all SFFs from an external point, with a red optical indicator to confirm activation.

  • Includes a compact SPD, caused by a short-duration high voltage surge, Type II according to IEC 61643-11 standard, powered by 230V AC 50Hz L+N.

  • Durable enclosure suitable for industrial and technical environments, with a protection rating ideal for both field and technical room installations.

  • Clearly labeled terminals and an optimized internal layout ensure fast, secure, and error-free wiring.

Code 029SFC06C
EAN 8430892365215
Dimensions
Product height 243
Product width 333
Product length 132
SFF Technical Data
AC disconnection circuit 230 V - 30 mA
Protection degree IP65 - IEC 60529
Base colour RAL7035
Standards UNE-EN 60670-22
