CP004025

ON-OFF SWITCH 4PX250 POLYESTER ENCLOSURE TRANSPARENT COVER
4-pole 250A switch-disconnector enclosed in glass-reinforced polyester box and transparent polycarbonate cover. RAL7035 color box. Exterior front operation by means of a safety handle padlockable in position 0. Interlock to prevent the opening of the enclosure under load. Enclosure measures 540x360x201. Double insulation box. Fully apparent cut. Visual supervision of the inside of the box. Degree of protection IP66 for the box and IP55 for the handle. High resistance to impact IK09.

Print to PDF

Code 017CP004025
EAN 8430892295147
Technical data
Nr. Poles 4
Air thermal rating (Ith) 250 A
Impulse voltage (Uimp) 8 kV
Minium Cu cable cross-section

95 mm2
Maximum Cu cable cross-section

150 mm2
Maximum Cu busbar width

32 mm2
Tightening torque 20/- Nm
Prostpective shortcircuit current (rms) 50 kA
Associated fuse rating 250 A
Rated short-time withstand current 1s (Icw) 9 kA
Standard IEC 60947-3
