55PV4040
SWITCH SIRCO 4P 400A 1000VDC
| Code | 01755PV4040 |
| EAN | 8430892229340 |
Technical data
| Nr. Poles | 4 |
| Operational rating (Ie) | 400 A |
| Air thermal rating (Ith) | 400 A |
| Impulse voltage (Uimp) | 12 kV |
| Maximum Cu cable cross-section | 185 mm2 |
| Maximum Cu busbar width | 32 mm2 |
| Tightening torque | 10 Nm |
