55HAC3020
ON-OFF LOAD BREAK SWITCH 3P x 200A - 1000V AC
| Code | 01755HAC3020 |
| EAN | 8430892319737 |
| Nr. Poles | 3 |
| Air thermal rating (Ith) | 200 A |
| Impulse voltage (Uimp) | 8 kV |
| Minium Cu cable cross-section | 70 mm2 |
| Maximum Cu cable cross-section | 95 mm2 |
| Maximum Cu busbar width | 32 mm2 |
| Tightening torque | 20/- Nm |
| Prostpective shortcircuit current (rms) | 80 kA |
| Associated fuse rating | 200 A |
| Rated short-time withstand current 1s (Icw) | 9 kA |
| Operational rating AC21 | 200 A |
| Operational rating AC22 | 200 A |
| Standard | IEC 60947-3 |
