ACM63SDA/300
AC MODULAR COMBINER BOX SINGLE PHASE MCB 63A RCCB TYPE A 30MA
Modular combiner box with mcb, rccb and overvoltage protection . Modular circuit breaker two pole 63A C curve breaking capacity 6kA - EN 60898-1. Residual current circuit breaker two pole type A sensitivity 30mA for alternating current with pulsed direct current, protected against nuisance tripping 0,25kA, EN 61008-1. Overvoltage protection ClassII In 20kA Imax 40kA Up 1,5kV EN 61643-11 with associated fuse protection. Double insulation Class II box in polycarbonate material for indoor and outdoor use with high impact resistance (IK08). Dimensions de 231x238x118mm
